Windows 10 | parameter is incorrect

Hi guys

I can’t confidently say whether it is the KB4557957 or something that deliberate by me, I had serious troubles connecting to IKEV2 VPN, ending with a message “Parameter is incorrect”.

Although I landed on the solution earlier, I disrespected the order & spent another day trying to figure out the “issues”. Finally I did as the post asks & “fixed” the problems. Enough talks, just follow the instructions as mentioned on this page

https://github.com/trailofbits/algo/issues/1051

regards,

rajesh

Advertisements

Windows 10 | Stuck in the boot

Hi guys

I hardly had any issues with Windows 10, to conclude my experience with this specific OS. I’ve started using the OS from the 1st preview builds, was an insider etc.

Yesterday I couldn’t start the OS. Windows logo loads, OS loading animation starts and that’s all. After breaking the load process thrice, Windows initiated the Automatic Repair process and loaded the OS after a considerable amount of time.

As a practice, from years, I always move the Documents and Download folders to a different partition for my user account. This saves me additional time to backup and restore the user files when I need to rebuild the box.

Once Windows finally started, from experiences, I started checking for the partitions and found that two of the partitions on which I had the Documents and Downloads folders “WERE” missing. Now the difficult task was to identify the physical disk. My machine has total 6 disks (2 SSD, 4 various capacity mechanical drivers & couple of them 6+ years old) & after a thorough examination, realized that the disk that was having the “Downloads” and “Documents” folders has a SATA cable that was not anymore holding up it’s physical connection on the port. Once changed, everything went back to normal. Actually the user profile was trying to access the missing disk, causing the lockup during boot.

So, if you have heavily customized desktop computers once in a while, make sure that your connections are in place. Every time you open the case, make sure you are having all the cables checked and insured that tightly secured!

regards,

Windows 10 | Java client will not load on Internet Explorer

Hello guys

Internet explorer? Java client? Yes! Oracle E-Business Suite (Oracle Apps) uses NPAPI client when accessed through a web browser for Oracle Forms/Reports based applications. Currently the only one browser that allows the NPAPI client to load is Internet Explorer.

Depending upon the complex JAVA dependencies your version of Oracle Applications must be supporting a particular version of java client. Although you can use switches to load latest versions of JRE for your legacy Oracle application, not always advisable as I’ve experienced non-responsiveness & freezing.

Windows 10 version 2004 (Released by late May 2020) & subsequent cumulative updates MUST be the reason, causes a major issue with Internet Explorer (as on 26th June 2020). Once you installed & removed a higher version of JRE, JRE 6.x will not load anymore on the browser. You can reset Internet Explorer, reset your JRE & what not? Trying to open the Oracle forms based application would show the plugin being loaded and that’s all!

Strangely, I can see this issue is with only JRE 6.x when JRE 7.x and later load as usual without any problems. So if you think you have tried “everything” already & landed on this page, let us give it another try.

You can divide the below tasks into two sections. If JRE 6.x is the only one java client remaining after removing all other versions & if the JAVA_HOME or other Java related keys are not set under environment variables, just delete the “Sun” & “Java” Folders from “AppData” “Roaming”, “LocalLow” & “Local” folders. You may delete the “Javasoft” entry from “Computer\HKEY_CURRENT_USER\SOFTWARE\JavaSoft” registry path also. Try to load Oracle forms based application and if the java client is NOT at all loading, follow the below instructions.

Uninstall Java Software

After uninstallation remove all remnants of Java software from the system.

This should open the appdata folder the current user.

Let us find and delete all “Java” and “Sun” folders and content within those folders. Please note, if you are using JAVA for other than accessing Oracle EBS, the following instructions may result disastrous situations. Hence I recommend you to continue with utter caution.

Delete “Sun” and “Java” folders as I have said before from “Roaming”, “LocalLow” & “Local”

Open RegEdit

and open the below path

Computer\HKEY_CURRENT_USER\SOFTWARE\JavaSoft

Delete the “JavaSoft” folder completely.

Now switch to “Computer\HKEY_LOCAL_MACHINE\SOFTWARE\WOW6432Node\JavaSoft”

This is the registry path where 32 Bit version of Java software is installed. Delete this folder also (if exists after uninstallation).

Now you are ready to re-install the Java client once again. I would prefer a computer restart prior attempting re-installation, which is not mandatory.

After the re-installation of JRE, opening the internet explorer should ask you for permission to enable the client and Oracle EBS should able to load the NPAPI client properly. Do let me know whether it helped you.

References:

Regards,

rajesh

Windows 10 network, action center, clock icons do not respond to mouse click

Hello guys

I started using Windows 10 from the early developer previews & was lucky until yesterday (24th June 2020). Few things didn’t work as expected then onwards.

I noticed the troubles when I clicked on the network icon on the taskbar, which usually pops up a window from which I can connect to another available connection or turn “Airplane Mode” on or off etc

Unfortunately, this has stopped on me all of a sudden. I started searching for a solution & came across few, which didn’t solve my issues. Today morning 25th June 2020, I noticed that it was not just the network connection icon, my clock and action center also had the same issue of not responding to mouse clicks!

  1. https://windowsreport.com/action-center-wont-open-windows-10/#:~:text=Open%20the%20Start%20Menu%20and,%3E%20Advanced%20options%20%3E%20Startup%20Settings.&text=If%20Action%20Center%20is%20working%2C%20restart%20your,and%20start%20Windows%2010%20normally.
  2. https://www.lifewire.com/fix-windows-10-action-center-wont-open-4588300

Please refer the above links for situation those may not be fixed by the below simple instruction. While trying to find a solution, accidently I landed on the below settings area & toggled the “Get notifications from apps and other senders” from on to off & then reversed it.

That was it! Toggling Notifications on and off has brought back the functionality to whole those icons which were not responding. Give it a try and let me know whether it helped you! (No need to restart the computer)

regards,

rajesh

FileZilla FTP Server with TLS

Hello guys

Today we will see how to setup FileZilla FTP server with TLS. Well there are many documents explaining it, however, as usual I am going one step ahead and explain few elements those are missed by most of those posts.

Once installed (accept the defaults, letting FileZilla run as a Windows service) you can start configuring it for PASSIVE mode transfers and TLS.

As you could see, the installation sets port 21 as default listening port for FTP. If you choose to, can change it an available port. Usually you don’t have to do it.

If your FTP server/desktop machine has multiple IP addresses, you may assign a particular IP for the FTP Server under “IP Bindings”

Leaving it to default will not hurt you, usually.

Setting up Passive Mode can be bit tricky, especially when you are going to let users from internet to access your FTP server. Let us consider you have a router that is the gateway for all your computers in the network. So any communication that is leaving your network passes through this router. This is called a NAT network. Getting a FTP server to respond to a request from internet could be quite confusing for someone who doesn’t understand the NAT properly (I don’t, all the time)

Usually such a requirement is handled by forwarding the requests received by the router to one of the servers or computers hosting the FTP or other services.

Here for FileZilla, the router should forward port 21 to the server that is hosting the FTP server, to that the communication and transfer could happen. So basically, your router should have an entry like below. With the given example, FTP Server software is installed on a computer that has STATIC IP address 192.168.1.200, hence the below entry. Please make sure that all your computers/servers those host services have STATIC IP addresses.

Please note, based on the manufacturer, Applications & Gaming tab will be labelled differently. You need to check the router manual to find out where exactly you can locate “Single Port Forwarding”. If you are lucky enough, you may able to pick FTP from an available dropdown list, like the one I have. Else, just create one entry like the one you could see with this image for FTP.

Now you need to configure the ports for Passive mode, which most of the modern FTP clients will try to use for the transfer. I believe, without configuring the passive mode, FileZilla FTP server fails to establish connections.

Here you could see that I am using a custom port range for Passive mode. Most of the people who successfully configured FileZilla recommend using the port range between 50000-51000. You can try the ranges like 50000-50100 or like the one I have, which is approximately a 1000 ports.

Next couple of points are going to be vital for users from internet. I have a static IP address from ISP, hence for the area External IP address, I can use it safely. However, this may not be the case of most home users, as ISP provide them dynamic IP addresses which keep on change once in a pre-planned interval. So http://www.noip.com is your friend and I suggest you create a ddns.net hostname for yourself before proceeding. You can use their client software to keep update your host IP address against ddns.net hostname. You can use your hostname, eg: johwick3.ddns.net in the place of external IP address.

OR

You can try the “Retrieve external IP address from” option as well. I cannot guarantee the success rate.

The other important setting on this page is “Don’t use External IP for local connections”. You must not uncheck this box in case if your FTP server has external IP configured and expecting both local and external users to access the server.

Once set, you need to open the range of ports on your router. This time you need to access the page “Port range forwarding” and create an entry like the seen below.

This completes the initial level settings for the FTP server. Let us configure TLS in the next step. This involves creating a self signed certificate and secret key (secret key is not mandatory). Luckily FileZilla has built-in ability to create a self-signed certificate for you!

Once you are on the FTP over TLS settings page, you can use generate new certificate button to bring this window up. Fill in correct information & generate the certificate. FileZilla will automatically setup the certificate for you. “Save key and certificate to this file:” should be chosen wisely. Your certificate is accessed from this location, so make sure that you will generate the certificate in a location/folder which is not accidently prone to get deleted.

Now we will create a new user & setup few details for the testing.

In the above step, I have created a user with read only privileges and assigned a single directory access. As long as you want your users NOT to upload files to your FTP server, this setup is sufficient for a normal user. Please refer FileZilla documents for in-depth knowledge about creating groups and users.

Finally, we will configure Windows Firewall in order to establish the connection. Please note, I am against disabling firewall and other security suites those are installed/configured on any environment, unless for testing. You must NOT disable them permanently. If your browsing and other internet activities are limited to reputed websites and services, I can insure that you don’t need a commercial product to protect your Windows box. The built in Defender suite does a wonderful job protecting your computer. Follow the below images to create an incoming rule for the FTP traffic in the very server/computer on with you have install FileZilla FTP server.

Please note, there is no need to open the port 990 that is used for TLS. Unfortunately while I was trying everything, included the port in my setup. You only need to allow TCP Ports 21 & the range 50000-51000 (or the port range that you prefer to use)

That’s all take for setup. We can try to connect to our FTP server now!

Download and install FileZilla FTP Client/Or one of the other FTP clients available (You may not succeed to connect to FTP server using Windows built in command line FTP, as it doesn’t support TLS)

As you could see from the quick connections area, I have connected to FTP server from both local and internet & both attempts were successful.

I hope, if you are desperately looking for FileZilla FTP server setup guidelines, this post helps.

regards,

rajesh

WSL2 | Windows Subsystem for Linux

Hello guys

Hope you and your loved ones are safe and secure during this tough period. I am home stuck from almost 3 months and hoping that the normality will resume very soon.

So, during the lockdown I’ve decided to take some “risks” by upgrading my production computers/laptop with the forthcoming version of Windows 10 2004 for Windows Subsystem for Linux aka WSL2 using Windows Insider preview ISO.

I work with real Linux enterprise servers at work & throughout last 10 years got myself accustomed with writing simple shell scripts and other Linux specific activities, so that I can handle them as comfortable as I interact with Windows Servers. I usually don’t get in to the silly arguments like which OS is better by comparing the features & other aspects. We never had issues with Windows Servers, neither had issues with Linux servers as we maintained them meticulously.

So, why subsystem for linux is important? Well, not many have the luxury of working with Linux servers. Especially students and developers from small business which depend completely on Windows environments. Subsystem for Linux on Windows opens doors for those who desperately need Linux environment & WSL is their friend. Unlike a virtual machine hosted on Oracle VirtualBox or VMWare, the user don’t have to dedicate hardware resources specifically for WSL & environment is always available. The only feature you may lack should be the ability to start the services automatically. Well, I am sure within a short time Microsoft will figureout a way to.

Okay, let us see how we can start availing WSL2 on Windows 10 already!

Please note, if you are not ready to take the responsibility of what you are going to do, please don’t attempt the below instructions which includes upgrading your Windows 10 version with yet to be officially released version of the same OS.

Once you upgraded your Windows 10 to version 2004

You are all ready to go. Please make sure that you have all the cumulative updates applied before proceeding.

Please note, if you are using Oracle VirtualBox on regular basis, I will suggest that you reconsider proceeding further. Enabling few of the Windows 10 features for WSL2 will completely compromise/degrade the performance of the Virtualizer and you will not even able to start your virtual machines (at times)

In order to avail the WSL2 functionality, you will have to enable few additional features of Windows 10.

I am upgrading my existing WSL to WSL2. If you are trying to configure WSL for the first time, Please refer documents explaining how to thoroughly (I have few posts towards enabling WSL with my blog, you may refer them)

You need to enable “Virtual Machine Platform” and restart the computer before upgrading WSL to WSL2.

Alternatively, you may use powershell as administrator to enable these features.

dism.exe /online /enable-feature /featurename:Microsoft-Windows-Subsystem-Linux /all /norestart
dism.exe /online /enable-feature /featurename:VirtualMachinePlatform /all /norestart

Please note, if you are using PowerShell, make sure that after enabling the features, you will restart the computer as both shell commands have /norestart switch

Once you restart the computer, you can try to upgrade your existing WSL to WSL2

Either from elevated PowerShell or CMD issue the following command

wsl --set-default-version 2

This is going to take a while, to complete. Once the upgrade has been completed you can start upgrading your existing WSL distros.

Before upgrading your WSL distros, you need to update the existing WSL kernel. Currently, you need to download and manually install the upgraded kernel, and let us hope Microsoft will include the kernel updates for WSL within their update packages.

Please visit the link https://docs.microsoft.com/en-us/windows/wsl/wsl2-kernel and follow instructions to download and install the kernel. Post installation, you can start upgrading your existing distros.

Open a command prompt as administrator and issue the following command

wsl --list --verbos

This should list all the distros you already have on your system and the corrsponding WSL version numbers associated

So, my work laptop has 2 distros and both are already upgraded to WSL2. Regardless, let us see how we can upgrade an existing WSL1 distro to WSL2

Consider my distro listing was showing VERSION information as “1” instead of “2”, then I would have issued the following command to upgrade my Ubuntu-18.04 distro

wsl --set-version Ubuntu-18.04 2

That’s all. Your distro will be upgraded to version 2.

My personal takes on WSL2

Well, my interest towards new features are limited to getting them installed and configured. I’ve had very limited handson with the upgraded Ubuntu distro and I was able to have a buttery smooth experiece with XRDP this time. To my utter surprise, Mozilla Firefox loaded without crashing & I felt I was truly interacting with a real Linux machine.

Please refer my previous posts towards WSL about installing XRDP, MySQL and other software those are usually configured on Linux environments.

Guys, almost every other tip and tricks I have listed are coming from many sites and I encourage you to visit those sites for further reading. All I have done was to put them in single place and to post this consolidated thread.

https://docs.microsoft.com/en-us/windows/wsl/install-win10

https://docs.microsoft.com/en-us/windows/wsl/wsl2-kernel

https://www.bleepingcomputer.com/news/microsoft/windows-10-2004-to-upgrade-wsl2-linux-kernels-via-windows-update/

I will be investing more time for WSL2 once after I get back to Office & hoping to post more interesting stuffs based on my findings. Until then, please stay safe and healthy.

regards,

rajesh

Windows 10 | Mobile HotSpot| We (don’t) have a solution

Hello guys

Cannot get the mobile HotSpot fully functional on Windows 10? Were you searching for a single stop solution, then you are at a very wrong place(?) move on. We are going to discuss about a strange behavior associated with, else almost a perfect solution provided by Microsoft for tethering the available internet connectivity.

At our corporate LAN, we use two different sets of IP addresses. One provided by the ISP (front facing) and the Class C IP addresses for the domain member computers and other devices.

We had a sysadmin laptop that is configured to use internet without filtering (AKA Watch Guard Edge device) by letting the traffic through the ISP router & a Class C IP address for LAN connectivity. Most of the sysadmins use the same settings for ease and had some difficulties with this particular laptop.

Mobile HotSpot starts, however the connected devices do not get IP addresses issued and no internet connectivity. Resetting IP & Winsock and windows provided troubleshooters didn’t fix anything & on a “divine” call we decided to change the IP addresses used.

For example, We had

168.x.x.204/255.255.255.224 (ISP) and 131.x.x.46/24 (LAN, don’t frown, we had these public IP ranges used within the LAN, dating back to 1990s) for the single network interface which didn’t work for Mobile HotSpot, so we changed the ISP IP address with an IP from another set of readily available public IPs and viola! the Mobile HotSpot sprang to life immediately.

We did route table matches between both IP settings and couldn’t find any differences, however, the first setup completely failing to issue IP addresses & connectivity. As we failed do the maths, gave it a rest and started “enjoying” the internet. Yay! So if you are in the same situation and have spare IP addresses, give it a try.

regards,

rajesh

Oracle SQL Developer 19.x.x & ORA-20001: Oracle error -6502: ORA-06502: PL/SQL: numeric or value error: character string buffer too small has been detected in fnd_global.set_nls

Hi guys

Okay, so you switched to Oracle SQL Developer for the main reason that the suite is from Oracle & it is absolutely free and putting loads of efforts to get accustomed with certain “JAVA” platform limitations (as per developers).

Everything is fine until you start getting “ORA-20001: Oracle error -6502: ORA-06502: PL/SQL: numeric or value error: character string buffer too small has been detected in fnd_global.set_nls” or errors those WERE never happening while you were trying to execute years old PL/SQL blocks which were always completing successfully using Quest TOAD or at SQL prompt itself.

Before scavenging through your archives to find the Toad Installer for a re-installation, give the following exercise a try.

Applicable to Windows ONLY!

Go to user specific “AppData\Roaming” folder, eg: C:\Users\rajesh\AppData\Roaming

and delete both the folders, “SQL Developer” & “sqldeveloper”

Usually whenever you download and start the latest version of SQL Developer, the new version checks for the older versions under Roaming profile & if found, prompts the user asking whether the existing preferences should be copied (that includes already saved connections and other setting you may have made), which may cause errors like the ONE I have had once after migrating 19.2.x to 19.4.x

Regardless whether you were using previous versions or NOT, deleting all folders for “SQL Developer” under the roaming profile will force the latest version of Oracle SQL Developer to start afresh & most probably will take care of unreliable error messages (Confirmed by running the PL/SQL blocks without outputting the same errors using Quest TOAD)

Thank me later ;)

rajesh

Windows 10 | Surround Sound & VLC Player

Hello guys

One of the most complicated “problems” I have had with Windows 10 was, using built-in “Movies & TV” instead of my favorite VLC Player, just because the later “fails” to play 5.1 surround sound, which I love

It looks like Microsoft Windows “Movies & TV” by default enables HDMI audio passthrough, thus surround sound is channeled rightfully.

Let us see a typical scenario:

  • Your PC is connected to a SmartTV that has Android TV (on HDMI Port 2)
  • Your TV is connected to AVR on ARC using HDMI (on HDMI Port 3)
  • Your PC shows your TV as your default “Speaker”
  • You setup 5.1 surround sound (unfortunately, you cannot test the setup us Windows doesn’t do the HDMI audio passthrough, instead the applications those are equipped with HDMI audio passthrough)

You try to play your video clip that has AC-3 6 channel audio, using VLC. What you hear is stereo only & toggling through the AVR’s different Audio formats do not do anything.

Now, here is the catch. By default VLC doesn’t enable HDMI passthrough. If you are using VLC 3.x.x versions, you can easily turn on the HDMI audio passthrough from Tools ->Preferences -> Audio

Select either “Enabled (AC3/DTS only) or Enabled. Switch to the one works for you.

Try to play the video again. One of the interesting factor I recognized that, once the HDMI/SPDIF audio passthrough enabled, VLC doesn’t care whether your speaker setup is surround (5.1, 7.1, x.x) or not. It just does the audio channel routing.

Try and let me know whether it works for you.

regards,

rajesh

Install Oracle forms & reports 12.2.1.4 with Weblogic 12c 12.2.1.4

Hi guys

This time we are going to see how we could install and configure Oracle forms & reports 12.2.1.4, the latest version using WebLogic Server 12c 12.2.1.4

Side Note: Kindly refer this document from Oracle https://docs.oracle.com/en/middleware/fusion-middleware/12.2.1.3/sysrs/system-requirements-and-specifications.pdf

The Visual C++ requirements mentioned for 12.2.1.3 should suffice 12.2.1.4 also, without which you will NOT able to startup OHS instance.

As a rule of thumb, regardless whether you are going to install and configure Oracle software on LINUX or Windows operating systems, always update the OS to latest patch levels, prior you start with the Oracle software installation(s). I strongly recommend using Oracle VirtualBox based Virtual Machines for the lab & later you may move the tried out solution to your preferred environments (TEST, Development). I don’t recommend any of the suggestions I make through my blog posts to be applied to PRODUCTION environments without consulting a Professional support entity.

Download Software from Oracle

Fusion Middleware Infrastructure Installer (Weblogic)

https://www.oracle.com/middleware/technologies/weblogic-server-installers-downloads.html

Oracle Forms & Reports 12.2.1.4

https://www.oracle.com/middleware/technologies/forms/downloads.html

JAVA SE Development Kit 1.8

https://www.oracle.com/technetwork/java/javase/downloads/jdk8-downloads-2133151.html

Install JDK

I prefer installing JDK on C: drive & Usually my JDK is installed on C:\Java\JDK folder. The shortest name, the best to handle it later. Once the 64Bit JDK is installed, you need to setup either JAVA_HOME environment variable or add a new entry in to the system path. I prefer a system path modification than user path modification.

Okay, there are hell loads of Oracle software installed on my system. Don’t worry, I manage them. Just make sure the JDK installation path is on top of the list and you are good to go

Install Weblogic Server 12.2.1.4

It may take a while for the jar file to extract and start the installer. Please wait patiently. I was setting up the entire infrastructure using Windows 10 VM & due to the limited resources, hence the entire ordeal was kind of time taking this time for me.

You can safely skip the Auto Update

Naming Oracle installation folders is an art. The complex the folder structures, the complex later configurations would be. I usually prefer to install all my Oracle software on D: drive. Please feel comfortable to format the Oracle home as per your requirements. Maintaining the same format helps me to locate and sometimes replace files from previous installations.

Select “Fusion Middleware Infrastructure”

WebLogic or Middleware installation is NOT complex anymore on Windows 10 OS. There are no special hacks needs to complete the installation.

Install forms & reports 12.2.1.4

Extract the downloaded zip file & you MUST start the installer as “Administrator”.

We’ve to install the Forms and Reports stack on an existing Oracle Home. So please select the Oracle Home where you have installed “WebLogic” Server. Alternatively you can always install the stack on a different Oracle Home, which I never tried earlier.

Select “Forms and Reports Deployment”, as the last two versions of Forms & Reports allow you to install a Standalone Forms Builder.

Select the correct JDK Home

Please make sure that you have Visual C++ libraries pre-installed prior proceeding. If you don’t have the VC++ libraries installed, the OHS instance will not start & you might experience additional problems during installation also.

That completes the Forms & Reports 12.2.1.4 installation.

Create a REPO for the Classic Domain

To create a classic domain, you must have a repository available with the database. Weblogic 12c supports Oracle 11G 11.2.0.4 or later database for the repositories & my pick will be always 12c Database as the 11.2.0.4 is only accessible for customers with valid Oracle support. You may refer this document for a detailed “how to” towards installing Oracle 12c database.

From an elevated command prompt, switch to Oracle Home\oracle_common\bin folder & execute “rcu.bat”

Check the below image for details

Choose the defaults

Provide the connection parameters. If the database is on another server, you don’t have to install additional clients, connection parameters will take care of the connection. Refer the below image for details (Adjust according to your database setup)

My 12c Database already has a repository for Forms & Reports 12c 12.2.1.3, hence I created a new prefix “DEV1”. If you are creating a repo for the first time, you can use “DEV” or any other 3 letter combination (make sure you will able to remember it laters).

Select all the components as seen with the below image. The selected are mandatory, especially the Metadata Services.

Use the same password everywhere! Unless you are setting up a production instance, use the same password everywhere. Example, I use “Abc1234” for the schemas, Weblogic Admin account, node manager etc, which makes the administration much easier. For production, follow the Oracle standards.

That completes the repository creation for a Classic domain.

Create a Classic Domain for deploying forms & reports application

From an elevated command prompt, switch to Oracle Home\oracle_common\common\bin (eg: D:\Weblogic\Middleware\Oracle_Home\oracle_common\common\bin) & execute config.cmd, that will kick start the classic domain configuration wizard.

Select the defaults, unless you have specifics. We will be creating a new domain with the following example.

Refer the below images and select the same components for a successful domain creation for forms and reports.

As I mentioned earlier, use the same password here, so that you don’t have to worry about forgetting & recovering it at later stages.

We will setup the domain for production (never tried Development, so don’t know how exactly both differ from each other). Leave the JDK selection as it is.

Now, your earlier created repository will come in act. Refer the below image(s) and adjust as per your environment

Make sure all the Schema validations are successful. Next step select components as per the below image

Make sure the Server Group is filled the value as seen with the below image. Don’t miss it!

We’ll add an instance OHS now. Click on the add button and refer the below images for more details

Fill in the Listen Address with “localhost” and leave rest to defaults

That finishes the creation of your classic domain.

You should able to access the newly created WebLogic admin server through the URL http://localhost:7001/console

I’m hurrying to publish the POST without further delays, as I am once again caught up with multiple assignments & keeping up with promises are NOT something I am look up to at this time. However, I will add up the missing configurations for OHS and setting up the Forms and reports very soon an an annexure as early as possible!

19th June 2020

Today I installed & configured another Weblogic Server environment & realized that I was supposed to amend this post with more details, is a long due!

I chose a Container+PDB 12c database instance for my Weblogic Server this time. It was fun, finally learning few things about Container and pluggable databases & I am hoping to write another post about setting up Weblogic, Forms and Reports with such a setup in near future.

Now without wasting more time, let us see how to finalize the freshly configured classic domain for Oracle Forms and Reports deployment.

Switch to the your newly created domain’s bin folder from an elevated command prompt. Eg:

“D:\Weblogic\Middleware\Oracle_Home\user_projects\domains\base_domain\bin”. Usually I always installed Oracle software on D: drive & follow the same naming structure for the folders. It helps me to backup and restore configuration & other files that help me to finish setting up the environments faster.

Start the nodemanger now by issuing the command by executing the command “startnodemanger.cmd”

It may take few seconds to minutes until the node manager starts for the first time. Please remember, you shouldn’t close this command window, which will automatically stop the node manager.

Open another elevated command prompt window and switch to your classic domain’s bin folder. Start the Weblogic admin server by issuing the command “startWeblogic.cmd”

Okay, with node manager, 99.9% chances that you may not bite bullet. With Weblogic Admin server, this is not the case. For number reasons, the Server will try to start and give up in the middle. So don’t panic. If the Weblogic Admin Server is not coming up to a “RUNNING” status after extended period of waiting, go ahead and restart your computer. Start node manager and then try to start the weblogic admin server once again.

The initial startup could take up to 5-6 minutes (depending upon your hardware, this time could vary) & you should see a status like below

Remember not to close the window, which will immediately stop the Weblogic Admin Server. The status of the window will keep on updated against the activities happening at the server side. Once started, you can safely keep both node manager and Weblogic Admin Server CMD windows minimized.

You can logon to the Weblogic Admin server from http://localhost:7001/console

Once after successfully logging in, this is the window you are presented with. We’ve to configure both Forms & Report servers now, by trying to start them. This process will keep on adding many elements to your start menu. Let us see we can start Forms (WLS_FORMS) & Reports (WLS_REPORTS) servers now

Click on the “Control” tab, select both “WLS_FORMS” & “WLS_REPORTS” from servers and press the “Start” button. Once start button clicked, you can press the refresh button to monitor the status of the Servers. Do not forget to click the refresh button again to stop refreshing once after the servers show the status “Running”

It could take minutes for both the servers to reach the “Running” stage. Keep watching the Admin Server command window for unexpected errors. If you have followed all the steps as I’ve instructed throughout my thread, I can confidently say that you shouldn’t have a single hick up until this moment.

Once both servers are running, we can complete the OHS setup finally. Open another elevated command prompt. Switch to Oracle_Common\common\bin folder

Eg: D:\Weblogic\Middleware\Oracle_Home\oracle_common\common\bin and start Weblogic Scripting Tool (wlst)

Now you can issue the command “ohs_updateInstances()” at the wlst prompt & once the configuration completed, exit wlst by issuing “exit()”

You can try to logon to Weblogic Enterprise Manager console and start the newly setup OHS instance now.

Logon to Weblogic Enterprise Manager from http://localhost:7001/em & click the Navigation menu by the left hand side and expand HTTP Server to view your newly created OHS instance. In our case “ohs1”. Click on “ohs1” to open the control panel for the instance

Click the Start up button to start the OHS instance & after showing you message window stating you cannot stop the starting/stopping process, OHS will start. It could take few seconds to minutes depending upon your hardware and available resources.

Give special attention to “Machine Name”.

Now we will see how to bring OHS instance in action by setting up the few other factors like node manager security, configuration files.

Logon to Weblogic console @ http://localhost:7001/console

Lock & Edit the domain security values, please refer the image below for details

nm

Provide a meaningful name for the node manager account and supply a password. I used the same password for the total 12c deployment, unless you are setting up a PRODUCTION instance, you may use the common password across the 12c instances for easy administration of objects when required. Shutdown the services (better). Once the node manager properties are changed, restart the WLS admin server. Please note, always stop all running servers (forms & reports) services prior shutting down the Admin server & I suggest you gracefully shutdown the Admin server by running “StopWeblogic.cmd” instead of using the Weblogic console.

Move to your Oracle Home folder. I have installed Weblogic server in D:\Weblogic\Middleware folder, hence my Oracle home folder is

D:\Weblogic\Middleware\Oracle_Home\

(Adjust your paths accordingly)

Edit forms.conf file in the folder D:\Weblogic\Middleware\Oracle_Home\forms\templates\config\

By default this template file comes with commented examples, like following

#<Location /forms/>
#        SetHandler weblogic-handler
#        WebLogicHost host
#        WeblogicPort port
#</Location>

You need to uncomment one of the blocks starting from <Location /forms> until </Location> & add properties specific to your deployment, for example, my computer’s name is “RAJESH-PC” and I am using default ports for both forms and reports applications, hence I have the properties set like following

<Location /forms/>
SetHandler weblogic-handler
WebLogicHost HOME-THEATER
WebLogicPort 9001
</Location>

Once altered, copy forms.conf to OHS instance “moduleconf” folder. I have copied the file to following location: (Alter according to your setup)

D:\Weblogic\Middleware\Oracle_Home\user_projects\domains\base_domain\config\fmwconfig\components\OHS\instances\ohs1\moduleconf

Now we will edit the configuration file for reports

Switch to “D:\Weblogic\Middleware\Oracle_Home\reports\conf” folder & edit “reports_ohs.conf” and add a block like following (alter according to your setup)

<Location /reports/>
SetHandler weblogic-handler
WebLogicHost HOME-THEATER
WebLogicPort 9002
</Location>

Copy the edited file to

D:\Weblogic\Middleware\Oracle_Home\user_projects\domains\base_domain\config\fmwconfig\components\OHS\instances\ohs1\moduleconf

Now the OHS instance know about the deployments and once after restarted, you can try to start the forms based application through the OHS instance, rather than calling it against the default port (9001)

Once the OHS instance is updated with the new information, try to start the OHS instance from a command prompt using storeUserConfig parameter

D:\Weblogic\Middleware\Oracle_Home\user_projects\domains\base_domain\bin>startComponent.cmd ohs1 storeUserConfig

ohs_manually

1st run, you will be prompted for node manager password, supply the password you have setup earlier and OHS instance should start without creating a fuzz in usual scenarios

In future if you want to start the OHS instance, unless made changes to the configurations, just run

D:\Weblogic\Middleware\Oracle_Home\user_projects\domains\base_domain\bin>startComponent.cmd ohs1

Above concludes the 1st of level of configurations for Oracle forms based application. You can use Weblogic 12c Enterprise Manager to configure most of the forms environment related parameters like forms path and other, while I am yet to find out relevant configuration areas for reports.


You can manually modify the formsweb.cfg & default.env files to start with as well

Regardless whether you are going to use the in-process report server or a stand alone instance of the reports, many changes should be made to the configuration files, so that you can call the reports server from a Forms module

Generally we will be modifying multiple configuration files, I will try my level best to provide the exact locations for the files which you should change according to your installation preferences

Configuration files path (Please note, through versions, there are minor changes happened to these configuration files. The images below were copied from my previous post about configuring for deployment, however the settings remain the same for 12.2.1.4 (as tested on 19th June 2020))

D:\Weblogic\Middleware\Oracle_Home\user_projects\domains\base_domain\config\fmwconfig\servers\WLS_REPORTS\applications\reports_12.2.1\configuration

  1. rwservlet.properties – Servlet specific properties
  2. rwserver.conf – Server properties
  3. cgicmd.dat – key mapping file

1. As far you are using in-process reports server, nothing much to alter with “rwservlet.properties” file. Basically you should see entries like following in the opened file:



2. rwserver.conf (Please check the below image)


3. cgicmd.dat: Many values we supply to call a report using Web.Show_Document method could potentially expose vital information like the database details & many other. “cgicmd.dat” file helps us to map such values to keys and later use them wherever applicable. With this example, I will demonstrate, how the database username, password and service name are mapped using a key. Please check the image attached below


Once these configurations files are altered, we need to create a report instance for the WLS_REPORT server. Open an elevated command prompt and switch to “D:\Weblogic\Middleware\Oracle_Home\oracle_common\common\bin”. Start wlst & connect to the server.

Issue the command

createReportsToolsInstance(instanceName='rptools1', machine='AdminServerMachine')

Note, you can choose your own name for the report instance. Once the report instance created, exit wlst and you can try to start the WLS_REPORT server from the weblogic console.

This comprehensive note should help you to quickly start with Oracle Forms & Reports 12c (12.2.1.4)

I am avoiding few elements like publishing a Forms based application for now. If you feel, should be added, please let me know through the comments section.

regards,

rajesh
