Oracle Database 19c | Convert non CDB Database to PDB

We’ve our Oracle EBS instance hosted from Linux environment. However I post much for the Windows OS as I see there are not many articles targeting Oracle on Windows. I think for better view counts, I should consider posting the articles for both OS.

In my last post about restoring 1g RMAN online backup to 19c non CDB database, I said my ultimate goal was to convert the upgraded database from non CDB to PDB, that is plugged on to an existing CDB. Let us see how to achieve this goal this time.

Before start, there are few mandatory checks you must do to insure a successful migration from Non CDB to PDB. I will list few of them those came as hurdles for me.

  1. Character Set. Make sure that your CDB and the Non CDB database have the same character set. There are few possible conversions. Please check 12c Multitenant Container Databases (CDB) and Pluggable Databases (PDB) Character set restrictions / ORA-65116/65119: incompatible database/national character set ( Character set mismatch: PDB character set CDB character set ) (Doc ID 1968706.1) for more details. My CDB was using Arabic character set and the upgraded non CDB database was using a noncompatible set. So I dropped the CDB and created a new CDB without PDB(s). Dropping a CDB will not be always possible because other PDBs are attached to it.
  2. Available storage space. This could be a real concern incase if you are planning to create a PDB, cross verify & then delete the non CDB database. You will need approximately the same size of your non CDB datafiles size storage available to do this activity. My database was less than 5 GB in size, hence it never occurred to me. If your database has a bigger size, plan accordingly.

Let’s do it now.

From and elevated command prompt (Windows Terminal is not yet matured enough to handle such “heavy” tasks) source the non CDB. Shutdown and startup mount exclusive.

C:\Windows\system32>set ORACLE_SID=KAZEMA
C:\Windows\system32>sqlplus / as sysdba
SQL> shu immediate
SQL> startup mount exclusive
SQL> alter database open read only;

Create manifest file for the non CDB now.

SQL> exec dbms_pdb.describe (pdb_descr_file=>'D:\Oracle19c\kazema_manifest_file.xml');
SQL> shu immediate

Source the CDB now.

C:\Windows\system32>set ORACLE_SID=KAZEMACDB
C:\Windows\system32>sqlplus / as sysdba
SQL> SHOW CON_NAME

CON_NAME
------------------------------
CDB$ROOT

Now, we need to see whether non CDB meets the compatibility requirements. There could be multiple elements those you may have to fix before, the non CDB is ready for a successful migration as PDB. You will have to refer PDB_PLUG_IN_VIOLATIONS view for these details. Go ahead, execute the below code block.

SQL>   SET SERVEROUTPUT ON;
SQL>    DECLARE
       Compatible CONSTANT VARCHAR2(3) :=CASE  DBMS_PDB.CHECK_PLUG_COMPATIBILITY
       (pdb_descr_file => 'D:\Oracle19c\kazema_manifest_file.xml')
       WHEN TRUE THEN 'YES'
       ELSE 'NO'
       END;
       BEGIN
          DBMS_OUTPUT.PUT_LINE(compatible);
       END;
     /
YES

My case I didn’t have incompatibilities blocking possible migration. Your case could be different. If the output is “NO”, run the following query (use SQL Developer for better view)

select * from PDB_PLUG_IN_VIOLATIONS where name='<your non CDB name>';

Fix each and every other ERROR & you can safely ignore the “WARNINGS” for now.

Proceed with creating a new PDB from the manifest file that we have created in the 1st step.

SQL> CREATE PLUGGABLE DATABASE KAZEMA USING 'D:\Oracle19c\kazema_manifest_file.xml' COPY FILE_NAME_CONVERT=('D:\ORACLE19C\DB\ORADATA\KAZEMA\DATAFILE','D:\ORACLE19C\DB\ORADATA\KAZEMA');

Pluggable database created.

SQL> show pdbs;

    CON_ID CON_NAME                       OPEN MODE  RESTRICTED
---------- ------------------------------ ---------- ----------
         2 PDB$SEED                       READ ONLY  NO
         3 KAZEMA                         MOUNTED

Once the PDB has been created, confirm the same & proceed with balance activities. Run “noncdb_to_pdb.sql”

SQL> alter session set container=KAZEMA;

Session altered.

SQL> @$ORACLE_HOME/rdbms/admin/noncdb_to_pdb.sql

Based on the resource available, this might take a while for the script to complete execution. Once completed you can try to open the PDB. Check for Errors and Warnings in the PDB_PLUG_IN_VIOLATIONS view. If there are new ERRORS & WARNINGS fix them.

A typical scenario could list you many things like this (reference image only)

After fix attempts, I am still left with one Warning about sys lock issues. This is mainly due to the password file format 12.2. I hope to find a solution soon for it. Status column states whether the Error/Warning was taken care off.

SQL> alter pluggable database open;

Pluggable database altered.

SQL> SELECT name, open_mode FROM v$pdbs;

NAME
--------------------------------------------------------------------------------
OPEN_MODE
----------
KAZEMA
READ WRITE


1 row selected.

SQL> show pdbs;

    CON_ID CON_NAME                       OPEN MODE  RESTRICTED
---------- ------------------------------ ---------- ----------
         3 KAZEMA                         READ WRITE NO
SQL>

Now you have a non CDB and PDB with the same SID. You can proceed with dropping the non CDB database after cross verifying the concerns.

Reference documents:

Foot Note: If you are plugging a database that was hosted in another server/computer after converting, make sure to verify the “local_listener” parameter for the PDB exist.

D:\Oracle19c>sqlplus / as sysdba

SQL*Plus: Release 19.0.0.0.0 - Production on Sun Apr 10 11:18:33 2022
Version 19.14.0.0.0

Copyright (c) 1982, 2021, Oracle.  All rights reserved.


Connected to:
Oracle Database 19c Enterprise Edition Release 19.0.0.0.0 - Production
Version 19.14.0.0.0

SQL> show parameter local_listener

NAME                                 TYPE        VALUE
------------------------------------ ----------- ------------------------------
local_listener                       string      LISTENER_KAZEMACDB
SQL> alter session set container="KAZEMA";

Session altered.

SQL> show parameter local_listener

NAME                                 TYPE        VALUE
------------------------------------ ----------- ------------------------------
local_listener                       string      LISTENER_KAZEMACDB
SQL>

If the local listener is not reachable, PDB level services will fail to register with listener and the applications those depend on such services will fail to establish connections. This applies mostly to Oracle E-Business Suite environments and could be mapped to sophisticated applications that use specific service names to establish connections to the database.

KB5009543 | Jan 2022 cumulative update breaks IKEv2 VPN Connections

KB5009543 or Cumulative update Jan 2022 for Windows 10 and Windows 11 is currently breaking IKEv2 VPN connections. If you are experiencing an unexpected connection failure with a vague error message like “General processing error”, please follow the below steps.

Go to Program and Features -> Installed Updates and uninstall KB5009543. Reboot the box and the VPN connection should start working normally. Optionally you may disable the Windows Update for a period of time so that the same update will not get installed once again. Please note, Microsoft releases updates to their products quite often to resolve issues those were identified. Few times these updates open new issues, like the one happened with this particular KB.

While there are no straight forward methods available to “stop” Windows updates, you can use multiple methods to disable Windows update completely, which we don’t recommend. One of them is using group policies on the local machine.

If you still consider disabling Windows updates temporarily/long term, please refer this excellent tutorial

Hope this helps.

Connecting Oracle Developer 10g to 11G database takes long time

We migrated to 11G R2 (11.2.0.4) for our Oracle Applications R12 few years back, yes few years back (2017) & lived with one of the worst experiences…

Connecting Oracle Developer 10g (Forms/Reports) suite to 11G database.

I have scavenged through community articles for long time before giving up. I hardly came across a single fix for the connection time that used to hang up the Developer suite at times…

Today, I decided to find a solution for the nagging SSH connection issues from Windows 11 to our LINUX application servers and realized that we didn’t update the DNS settings for them once after we decommissioned a domain controller. Once the SSH issues were rectified and addressed, my next attempt was to find a solution for “frmcmp_batch” taking long time to start compiling modules & I landed on the below post.

Credit: Oracle Applications DBA: Form Compilation Against a 11g Database Hangs or Takes a Very Long Time [ID 880660.1] (appsjagan.blogspot.com)

As we are already on 11G R2 11.2.0.4, patching was not required. All I needed was to alter the hidden parameter “_FIX_CONTROL” as mentioned in the article.

SQL> ALTER SYSTEM SET "_FIX_CONTROL"='8560951:ON';

(Use scope=spfile to make this change permanent. This will require you to restart the database.)

I opted to go without spfile for testing & as soon as applied, the “frmcmp_batch” started compiling the modules instantly, against the usual delay that ran into many minutes other times.

Out of curiosity, I tried to connect to the database from Developer 10g & the connection was instant! within a fraction of a second.

So DNS being one of the most important elements establishing successful connections, patches and fixes also play crucial role in providing stable connections. Were you stuck with the same issue? give the solution a try and let us know whether it helped you also.

Install Oracle Developer 10G on Windows 11

Today I re-installed Windows 11 on my computer. Actually I had upgraded from Windows 10 to Windows 11 on October 5th, 2021 the same day Microsoft released the half baked OS to public & all of a sudden I realized that, it was a blunder. So, after regretting over a month, I decided to re-install the OS and started installing all my development tools & you know what, I had to refer my Windows 7 post for installing Oracle Developer Suite 10g on my Windows 11!

Much of the post below is from the earliest post that I had for Windows 7, explaining hacks to install Oracle Database 10g and the Suite. Oracle Database 10g is not anymore significant, hence I removed the database part and posting the rest for few unfortunate Oracle developers out there. Well, 10g is used by many business application as on date & if you are looking for a method to install Oracle Database 10g on Windows 11, Please search the blog for Database 10g and you will land on multiple posts explaining to how (Refer Windows 10 articles)

Step 1 Setup Virtual Memory

If your computer has 8GB or more physical memory, all you need is to setup the Virtual Memory for the name sake. Limit the virtual memory to 2048 (2G) or max 4096 (4G). Please use the below images only for reference purposes. After changing the Virtual Memory, You will be asked to restart the computer and please restart.

Step 2 Setting up the Developer Suite

Depending upon the media that you are using for the installation, Oracle Developer 10g has 2 discs & I have copied the content from both disks inside a folder on my computer. (As you could see in the image above)

Open the Disk 1 folder and locate “Setup.exe’, right click and change the compatibility to Windows XP Service Pack 2 or 3 (doesn’t make any difference)

That’s all. Right click and run “setup.exe” as Administrator. If you have a JAVA installation already on the computer, you might receive a warning message for missing entry point, that you can safely ignore.

Follow the same compatibility setting for patch sets, if you have any. Let me know about your experience through comments.

Windows 11 | Dial a VPN Connection using PowerShell script

I started blogging once after upgrading to Windows 7 & posted mostly about the ridiculous bugs Microsoft exported with that OS. Gradually Windows 7 got matured (hardly ever fixing the yellow triangle network icon issue) & my entire attention switched to what I do for salaries, Oracle development & later much of my posts were about the stack.

Now Microsoft has released another half cooked OS, Windows 11. From a layman perspectives I cannot understand how someone could make such decisions that affect the established stability and ease of use of an OS that creates huge disappointments for general userbase!

Other than cosmetic changes and revamped settings area, I cannot defer Windows 11 from Windows 10, plus the disappointment of losing the start menu that I was getting used to after loads of patience and efforts. Among many of such grievances, connecting to VPN at work is so ridiculous, requiring 4 mouse clicks! So I decided to go with a cmd/powershell script this time to avoid those 4 mouse clicks.

After weighing the possibilities of extending , I decided to go with PowerShell (Version 5)

So let us check how it works. Copy the following in to a text file

rasdial.exe "Your VPN Name"

Save the file as “Dial VPN.ps1” or any other name you prefer with extension “.ps1”.

Make sure you wrap the VPN name using double quotes. “rasdial.exe” is not a powershell cmdlet, an old Windows OS friendly dialer. This executable is generally found in the Windows\System32 folder and there is no need to specify the path, unless you modified the PATH environment variable. Now create a new shortcut on the desktop and type/copy the following (Please adjust the file path as per your setup) as command for the shortcut

powershell.exe -File "C:\scripts\Dial-VPN.ps1"

Usually I keep all my scripts in a folder named “Scripts” on the C: drive. Hence the -File parameter clearly mentions the script’s path.

That’s all, you can double click and open the pre-configured VPN connection without going through the 4 click hassles on Windows 11 (or multiple clicks on other Windows OS versions)

Now, let us look at a fancier version of the above. What if you want to connect if not connected and disconnect if already connected? Please note, this script could be extended beyond this level depending upon specific requirements. I have started with the skeleton and will be happy to receive better scripts from you.

#https://community.spiceworks.com/topic/2271983-auto-connect-vpn
#http://woshub.com/popup-notification-powershell/

$vpnname = "Your VPN Name"
$vpnusername = "YOURUSERNAME"
$vpnpassword = "YOURPASSWORD"
$cmd = $env:WINDIR + "\System32\rasdial.exe"

try{
$vpn = Get-VpnConnection -Name $vpnname -ErrorAction Stop
Write-Host $vpn.ConnectionStatus
}
catch {
$message = $_
$wshell = New-Object -ComObject Wscript.Shell
$Output = $wshell.Popup("Failed to retrieve Connection status. $message",0,"VPN Connection Status",64)
}

if ($vpn.ConnectionStatus -eq "Disconnected")
{
$expression = "$cmd ""$vpnname"" "
Invoke-Expression -Command $expression
$wshell = New-Object -ComObject Wscript.Shell
$Output = $wshell.Popup("VPN Connected",0,"VPN Connection Status",64)
}
else {
$wshell = New-Object -ComObject Wscript.Shell
$Output = $wshell.Popup("Your VPN Connection will be disconnected, Are you sure?",0,"VPN Connection Status",4+32)

if($Output -eq 6){
$expression = "$cmd ""$vpnname"" /DISCONNECT"
Write-Host $expression
Invoke-Expression -Command $expression
$wshell = New-Object -ComObject Wscript.Shell
$Output = $wshell.Popup("VPN Disconnected",0,"VPN Connection Status",64)
}

}
#start-sleep -seconds 30


Please note, I am a beginner with PowerShell(Also) and always will be. As usual, I have provided the links to original codes & possible other links those helped me to device the above.

The above can, dial your VPN connection, warn you before you disconnect etcetera. For my ease, I prefer to use the extended version of the script as I keep on switching the connections. You may able to extend the script once again by accepting the VPN connection name, so that you can use the same script for dialing different VPN connections (if you have many)

Have suggestions? please pass them to me through the comments section.

Windows 11 | Remote Server Administration Tools (RSAT)

A wonderful article about installing RSAT (Remove server administration tools) on Windows 11 is available at How To Install RSAT On Windows 11 PCs HTMD Blog (anoopcnair.com)

I would like reiterate something Anoop has mentioned in his article. If you are using Microsoft SCCM or Windows Update Services (WU), then you must enable the local group policy as he has mentioned clearly in his post.

The image attached by Anoop could be bit confusing for the local group policy setup, hence I am uploading one with better visibility. The path is “Computer Configuration->Administrative Templates->System” & you need to open “Specify settings for optional component installation and component repair”

No need to reboot the computer for installing RSAT components. Follow Anoop’s thread and be a happy Administrator!
